Tigo Energy TS4-A-O UHD 700W Power Optimizer 1.2M Cable - MC4 (Yellow)

This is an advanced Module-Level solution designed for seamless integration into existing and new solar energy systems. The Tigo TS4-A-O optimizer enables independent monitoring and maximum energy yield per panel, even with partial shading, orientation differences, or mismatch. The 'Yellow' colour coding in Tigo’s system signifies optimisation.

Key Features of the TS4-A-O UHD

Higher Capacity: This optimizer supports PV modules up to a power of 700W using UHD (Ultra High Definition) technology.
MPP Max. Voltage Range Input: 80 V
MPP Min. Voltage Range Input: 16 V
Max. Input Voltage DC: 80 V
Add-on module integration for maximum flexibility and deployment.
Offers integrated functionalities for Optimisation, Monitoring, and Rapid Shutdown at the panel level.
Equipped with a 1.2-metre cable and standard MC4 connectors for quick coupling.
Simple and fast assembly

Main Advantages

Maximum Energy Efficiency: Provides precise module-level tracking to maximise the yield of the entire system under challenging conditions.
Comprehensive Monitoring: Ensures detailed and continuous insight into the performance of each individual module, simplifying diagnostics and maintenance tasks.
Remote Troubleshooting with Tigo Access Point (TAP) and Cloud Connect Advanced (CCA)
Flexible Compatibility: Works universally with a wide range of standard PV modules and most inverters, ensuring high system design flexibility.
Ease of Installation: The plug-and-play design and pre-assembled MC4 cables significantly minimise on-site assembly time.
Enhanced Safety: Complies with the required Rapid Shutdown standards, which is essential for the safety of installers and emergency services.

Applications

This product is highly suitable for residential and commercial solar energy projects where shading, different roof pitches or orientations are present, or where module-level optimisation is required. The add-on functionality makes the optimizer ideal for both new installations and for improving the efficiency of existing (retrofit) PV systems.

Warranty and Technical Specifications

The device is extremely weather-resistant with an IP68 rating, guaranteeing reliable operation in diverse outdoor environments. The operational temperature range ensures consistent performance under extreme weather conditions. Tigo Energy offers a standard 25-year product warranty for the TS4-A-O series, underlining its longevity and durability.
