# Trina Vertex S+ N-Type Dual Glass 500W - Triple-Cut 1500V Black Frame Solar Panel - Art.No.: TSM-500-NEG18R.28

## Specifications

- **Brand**: Trina Solar
- **HS code**: 85414300
- **Manufactor**: Trina Solar
- **Net Height**: 30 MILLIMETER
- **Net Length**: 1961 MILLIMETER
- **Net Weight**: 23.5 KILOGRAM
- **Net Width**: 1134 MILLIMETER
- **Origin**: China
- **Backsheet**: white
- **Cell technology**: N-type TOPCon
- **Connector type**: MC4-EVO2
- **Max. output power**: 500 WATT
- **Number of bypass diodes**: 3
- **Number of cells**: 108
- **Color frame**: Black
- **Type**: Glass-Glass
- **Glass with anti-reflection coating**: Yes
- **Warranty in Years**: 25

## Advantages of Trina Solar Vertex N Dual Glass MONO 500W Black Frame


- 22.7% module efficiency
- n type i-TOPCon technology.
- Durable Dual-Glass Design
- Enhanced resistance to salt spray, acids, alkalis, and extreme temperatures.
- Fire Safety
- Compatible with mainstream inverters, optimizers, and mounting systems for seamless integration.
- Easy Installation
- 25 years product warranty




The Trina Vertex N Dual Glass MONO 500W is part of the new generation Trina Vertex S+ NEG18R.28 series. It’s a monocrystalline solar panel equipped with the n type i-TOPCon technology with a maximum power output of up to 500W. It’s a state of the art solution ideal for commercial and industrial rooftop systems.


## Efficiency and performance


The monofacial, dual glass modules deliver an efficiency of up to 22.7%, with a maximum degradation of 1% within the first year and an annual degradation of 0.4%. It’s the first module for large rooftops with dual glass structure. Dual glass enhances resistance to environmental factors such as salt spray, acids, high temperatures and humidity. The glass serves as a symmetrical sealant thereby enhancing fire safety. Replacing the plastic backsheet with glass also lowers the environmental footprint and the end of life recyclability. Making it an eco-friendly choice for commercial and industrial rooftops.


## Universal Compatibility and Easy Installation


Designed for universal compatibility, this model seamlessly integrates with mainstream inverters, optimizers, and mounting systems, offering easy installation across various applications. Due to the length of under 2m and the lightweight of 23.5kg, the dual glass design makes it easier to handle and install on site.

## Downloads

- [DataSheet NEG18R.28 EN](https://cdn.estg.eu/p/6/4/0/0/64004df9e2e6724c8bc92997184bd46524c11f6f_DataSheet_NEG18R.28_EN.pdf)
- [Trina PFAS free certificate SGS 2024 05 03](https://cdn.estg.eu/p/b/a/5/b/ba5b6401853a8e49210cebc629d78bbe3f92f253_Trina_PFAS_free_certificate_SGS_2024_05_03.pdf)
